THESE DRAWINGS ARE THE PROPERTY OF QUALTEK
ELECTRONICS AND NOT TO BE REPRODUCED FOR
OR COMMUNICATED TO A THIRD PARTY WITHOUT
REV.
B
C
DESCRIPTION
RoHS Compliancy
Updated Operating Temp
REVISION
DATE
06-01-06
10-27-09
APPROVED
DP
LY
THE EXPRESS WRITTEN PERMISSION OF AN OFFICER
OF QUALTEK ELECTRONICS.
PHYSICAL DIMENSIONS:
ELECTRICAL CHARACTERISTICS:
1-1. VOLTAGE RATING...................................115/250VAC
1-2.
CURRENT RATING
1
5
3
?0.188
1-3.
A. @ 115 VAC..........................................3 A RMS MAX
B. @ 250 VAC.........................................3 A RMS MAX
OPERATING FREQUENCY......................50/60Hz
1-4.
LEAKAGE CURRENT: EACH LINE TO GROUND
A. @ 115 VAC 60Hz............................0.50 mA MAX
2
2.38 ± 0.02
4
1-5.
B. @ 250 VAC 50Hz.............................1.00 mA MAX
HIPOT RATING (FOR ONE MINUTE)
A. LINE TO GROUND...........................2250 VDC
B. LINE TO LINE.....................................1450 VDC
2.77MAX
1-6.
MINIMUM INSERTION LOSS IN dB: (AT 50 OHM SYSTEM)
FREQ. MHz
.01
.05
.10
.15
.50
1.0
5.0
10
30
3.25MAX
COM. MODE dB
DIF. MODE dB
1
0
6
1
10
15
12
25
20
50
30
60
60
45
60
50
45
50
1-7.
1-8.
1-9.
OPERATING TEMPERATURE.................-25° TO +100° C
SAFETY:
RoHS COMPLIANT
CONTROLLED
SCHEMATIC:
Dim
range
Tolerance
+/-
Qualtek Electronics Corp.
PPC DIVISION
L1:
L2:
C1:
C2:
R:
1.00mH
30.0uH
0.22uF
3300pF
330K ?
(mm)
0-1
1-6
6-18
18-50
50-120
120-250
250-500
(mm)
0.15
0.20
0.30
0.50
0.70
0.90
1.20
Part Number:
Description:
Drawn / Date
B.ZHANG
02-10-03
850-03/001
EMI FILTER
UNIT: in
Checked / Date
02-10-03
REV. C
Approved / Date
JJH / 02-10-03
